You will get Electronics Schematic / PCB Layout Review
Project details
I will provide a complete schematic and layout review service, checking for issues both with the schematic and final layout. I will provide a report detailing any recommended changes or improvements, which will be broken down by severity. Once these changes have been completed, the project can be resubmitted for an additional review to ensure success when ordering protypes.
What's included
| Service Tiers |
Starter
$50
|
Standard
$150
|
Advanced
$300
|
|---|---|---|---|
| Delivery Time | 2 days | 5 days | 14 days |
Number of Revisions | 2 | 3 | 3 |
Optional add-ons
You can add these on the next page.
Fast Delivery
+$25 - $100
1 review
(1)
(0)
(0)
(0)
(0)
This project doesn't have any reviews.
AK
Artem K.
Mar 17, 2024
Esp32 firmware: esp-now + bt classic
It was a pleasure to work with Sam!
About Sam
Embedded Hardware + Software Design and Review, Product Design, CAD
100%
Job Success
Ipswich, United Kingdom - 4:07 pm local time
- Embedded C, ESP-IDF, STM32 and PIC microcontroller experience
- Detailed schematic design in both analog and digital domains
- Full project management including production and delivery of prototypes
Steps for completing your project
After purchasing the project, send requirements so Sam can start the project.
Delivery time starts when Sam receives requirements from you.
Sam works on your project following the steps below.
Revisions may occur after the delivery date.
Schematic Review Completion
The first step is to complete a full review of the schematic, ensuring component compatibility, wiring errors and any potential improvements.
PCB Layout Review Completion
Next, the PCB layout will be reviewed to check for shorts, poor loop areas, insufficient grounding and any potential improvements.
