You will get professional Schematic, Multi Layer PCB Design, Gerber and BOM files
Rising Talent
Project details
With over 5 years of experience in system design across power supply, consumer electronics, telecom, and RF boards, I deliver professional Schematic, Multi Layer PCB Design, Gerber, and BOM files tailored to your project needs.
I specialize in high-speed designs, impedance matching, delay tuning, differential routing, and complex multi-layer boards. My hands-on expertise includes Xilinx (Spartan, Virtex) and Altera (Cyclone) FPGAs, plus DDR2/DDR3 memory PCB designs.
You will receive comprehensive, high-quality deliverables, including:
Professional schematic capture (hierarchical included)
Multi-layer PCB layout & routing
Complete Gerber + drill files (ready for fab)
Detailed BOM
Tools I use:
Altium Designer 24
Cadence Allegro (17.2–24.1) + SKILL automation
Mentor PADS / Expedition
KiCad, Eagle, DipTrace, OrCAD, etc.
CAM350, ODB++, panelization, Gerber/DRILL mods
Standards & extras:
All footprints IPC-7351 compliant
Component library creation & management
Microcontrollers: STM32, MSP430, ATMEGA, A20, etc.
Reverse engineering (2–4 layers)
Obsolescence handling, BOM optimization, ECRs
Fast, DFM-compliant, manufacturing-ready deliverables.
Message me your project specs!
