You will get Autodesk Revit, Dynamo 3.6, DesignScript
Project details
This project provides a robust Dynamo-driven automation system specifically designed to generate complex steel frame structures within Revit. By bridging the gap between computational logic and structural engineering, the script eliminates the manual repetition of placing individual members, allowing you to move from conceptual grid lines to a fully detailed structural model in seconds.
Field of Expertise
Structural EngineeringBuilding Type
ResidentialBIM Software
Autodesk Revit, Dynamo Studio, Autodesk AutoCADFile Format
RVT, DWG, IFCWhat's included
| Service Tiers |
Starter
$50
|
Standard
$75
|
Advanced
$100
|
|---|---|---|---|
| Delivery Time | 2 days | 2 days | 2 days |
Number of Revisions | 0 | 0 | 0 |
Optional add-ons
You can add these on the next page.
Additional Revision
+$10
Additional Parametric Family
(+ 3 Days)
+$50
Additional Material
(+ 1 Day)
+$5About Muhammad Assem
AEC |Civil & Structural Engineering | Structural Engineering Expertise
6th of October City, Egypt - 8:51 am local time
Steps for completing your project
After purchasing the project, send requirements so Muhammad Assem can start the project.
Delivery time starts when Muhammad Assem receives requirements from you.
Muhammad Assem works on your project following the steps below.
Revisions may occur after the delivery date.
Discovery & Logic Mapping
We begin by defining the exact geometric rules and structural logic your steel frames require. I will review your sample Revit models and families to identify the necessary parameters for the script.
