You will get design/shop drawings, bar-bending schedules, quantities/takeoff for bridge
Rising Talent
Project details
You will get bespoke Civil/Structural engineering drawings(rebar/reinforcement detailing) of bridge foundations,piles, pile caps, piers, hammerhead piers, bearings and AASHTO bridge girders for all types of Reinforced Concrete bridges. Comprehensive drawings include either Steel pipe piles or RCC piles. You will also get architectural visualization and rendering of the Civil/Structural infrastructure.
The drawings include structural/design drawings, shop drawings, working drawings, post-tensioned tendons drawings, precast concrete details and miscellaneous drawings too.
