You will get industrial steel detailing and Tekla fabrication drawings
Project details
You will get accurate, fabrication-ready steel detailing and Tekla BIM modeling for heavy industrial projects such as steel plants, cement factories, conveyors, cranes, platforms, pipe racks, and industrial structures.
With over 20 years of industrial experience, I specialize in Tekla Structures modeling, shop drawings, GA drawings, connection detailing, material take-offs, NC/DSTV files, and BIM coordination for fabrication and construction workflows.
I focus on practical, buildable, and high-quality deliverables that help contractors, fabricators, and engineering teams reduce errors, improve coordination, and increase project efficiency.
Deliverables may include Tekla models, fabrication drawings, erection drawings, BOMs, NC files, IFC exports, and detailed steel documentation.
With over 20 years of industrial experience, I specialize in Tekla Structures modeling, shop drawings, GA drawings, connection detailing, material take-offs, NC/DSTV files, and BIM coordination for fabrication and construction workflows.
I focus on practical, buildable, and high-quality deliverables that help contractors, fabricators, and engineering teams reduce errors, improve coordination, and increase project efficiency.
Deliverables may include Tekla models, fabrication drawings, erection drawings, BOMs, NC files, IFC exports, and detailed steel documentation.
Field of Expertise
Structural EngineeringBuilding Type
IndustrialBIM Software
Autodesk AutoCAD, OtherFile Format
DWG, IFC, NWD, STEP, OtherWhat's included
| Service Tiers |
Starter
$150
|
Standard
$450
|
Advanced
$1,200
|
|---|---|---|---|
| Delivery Time | 3 days | 5 days | 7 days |
Number of Revisions | 1 | 2 | 3 |
Number of 2D Drawings | 3 | 8 | 18 |
Level of Detail | 300 | 350 | 400 |
Number of Renderings | 0 | 0 | 0 |
Design Analysis | - | - | - |
Architectural Walkthrough | - | - | - |
Native BIM Source Files | - | ||
Model Audit & Verification | - | - |
Optional add-ons
You can add these on the next page.
Fast Delivery
+$45 - $180
Additional Revision
+$45
Additional 2D Drawing
(+ 1 Day)
+$45Frequently asked questions
About SOHEIL
Senior Industrial Steel & Tekla BIM Specialist
Istanbul, Turkey - 12:51 am local time
✅ CORE SERVICES:
• Steel Detailing & Fabrication Drawings (Tekla Structures)
• 3D Modeling & BIM for Industrial Structures
• Mechanical Equipment Modeling & Installation
• AutoCAD Shop Drawings & GA Drawings
• BOM, Cutting Lists & DSTV Exports
• Project Coordination & Technical Office Management
• Workshop Operations & Site Execution Support
✅ PROJECT EXPERIENCE:
• Cement Plants (4,500+ tons steel structures)
• Steel Plants & DRI Projects (3,200+ tons)
• Material Handling Systems & Conveyors
• Industrial Dust Collection Systems (50,000 m³/h capacity)
• Heavy Steel Structures (11,000-ton commercial project)
• Fabrication Portfolios (21,000+ tons exposure)
✅ DELIVERABLES:
• Accurate shop drawings aligned with fabrication requirements
• 3D models with connection details and sections
• Assembly/workshop drawings (PDF, DXF, DSTV)
• Production-oriented detailing for workshop execution
• Mechanical equipment installation drawings
I bring practical workshop and site execution knowledge to ensure drawings are fabrication-ready and installation-friendly. Led teams up to 94 personnel across workshop and site operations.
Ready to start your project? Let's discuss your requirements.
Steps for completing your project
After purchasing the project, send requirements so SOHEIL can start the project.
Delivery time starts when SOHEIL receives requirements from you.
SOHEIL works on your project following the steps below.
Revisions may occur after the delivery date.
Project Review & Requirement Analysis
Review project drawings, specifications, reference files, and client requirements.
Tekla Modeling & Steel Detailing
Create accurate industrial BIM models, shop drawings, GA drawings, and steel detailing based on the project scope.
