You will get SolidWorks manufacturing drawings with GD&T from your model or sketch
Top Rated
Project details
You get production-ready SolidWorks work from someone who lives inside manufacturing every day — not just a CAD operator. I'm a certified SolidWorks professional (CSWA + CSWPA-DT, Dassault Systemes) with 14,000+ hours delivered on Upwork as a Top Rated Plus freelancer, including 7,400+ hours of drawing work for a single US machine shop. I model parts, sheet metal, weldments, and assemblies, and produce manufacturing drawings with GD&T that machinists can actually work from. Because I also do production planning and purchasing in a CNC environment, my drawings anticipate how parts get quoted, fixtured, and inspected — which means fewer RFIs, fewer bad quotes, and faster time to the floor. Every package includes print-ready PDFs plus native SolidWorks and STEP files, delivered on time with clear communication in fluent English and US business-hours overlap.
Materials
MetalField of Expertise
MachineryDesign Software
SolidWorksFile Format
DWG, PDF, SLDDRW, SLDPRT, STEPWhat's included
| Service Tiers |
Starter
$50
|
Standard
$120
|
Advanced
$250
|
|---|---|---|---|
| Delivery Time | 2 days | 4 days | 7 days |
Number of Revisions | 2 | 3 | 3 |
3D Modeling | |||
Texturing & Lighting | - | - | - |
Animation | - | - | - |
Source Files |
37 reviews
(29)
(8)
(0)
(0)
(0)
This project doesn't have any reviews.
SA
Sakib A.
Apr 26, 2024
CAD developer is needed to re-draw prints for manufacturing
Sakib has been an invaluable asset to Camco on Upwork, excelling in Excel formulas, and CAD drafting especially in Solidworks, and providing indispensable support to our president. Due to his exceptional performance, we're thrilled to promote him to a higher position within our company. Sakib's dedication and expertise make him an indispensable part of our team.
VG
Valencio G.
Jan 9, 2024
Industrial Design
MG
Michael G.
Aug 26, 2023
You will get 2d drawing with solidworks 3d modeling rendering cad drawing patent drawing
Great working with Sakib. Quick communication with anything that was unclear and worked expeditiously to make changes. Would recommend 10/10
EW
Emanuel W.
Aug 3, 2023
3D CAD production drawings
RA
Richard A.
Jul 1, 2022
CAD developer is needed to re-draw prints for manufacturing
About Sakib
Procurement & Planning | SolidWorks CAD | On-Time, On-Budget Delivery
100%
Job Success
Dhaka, Bangladesh - 3:09 pm local time
RESULTS MY CLIENTS MEASURE
• 5-10% typical cost reduction on purchased parts through competitive requoting
• 95%+ monthly on-time shipment sustained as Senior Engineer, Production Planning (vivo)
• GD&T manufacturing drawings machinists work from without RFIs — fewer revisions, faster quotes
• Manual reporting hours reduced to minutes through AI automation
• 7,400+ hours delivered to a single US machine shop at a 5.0 rating — a multi-year engagement
CORE SERVICES
1. PURCHASING & PROCUREMENT — WITH AI-AUTOMATED REPORTING
Supplier identification and qualification across the US and China. RFQ management with normalized bid analysis — realistic MOQs, lead times, and landed cost. PO tracking, expediting, sample coordination, and pre-shipment quality control. Every engagement includes AI-automated reporting: order trackers and live dashboards built on advanced Excel (formulas, Power Query) and Python, replacing hours of manual updates.
2. PRODUCTION PLANNING & MASTER SCHEDULING
Creation and maintenance of master production schedules integrating machine capacity, material availability, manpower, and customer due dates — with daily performance tracking, bottleneck identification, and recovery planning.
3. SOLIDWORKS CAD DESIGN — CSWA & CSWPA-DT CERTIFIED
Parts, assemblies, and sheet metal. GD&T manufacturing drawings, reverse engineering of physical components, and DFM reviews. Deliverables: native SolidWorks, STEP, and print-ready PDF.
4. CUSTOMER COMMUNICATION & COORDINATION
Currently serving a US manufacturer remotely as the single point of contact between customers and the production floor: order status, delivery commitments, expediting, and executive-ready reporting.
WHY ORGANIZATIONS RETAIN ME
Degreed mechanical engineer with factory-floor experience spanning purchasing, planning, design, and customer management. I buy parts knowing what the drawing requires, schedule production knowing what the customer was promised, and design parts knowing how they will be quoted. The result: fewer surprises, lower costs, and delivery commitments that hold.
ENGAGEMENT MODELS
• Project-based — sourcing projects, schedule builds, or CAD packages with fixed scope and price
• Retainer — your purchasing desk, master schedule, or drawing queue managed continuously
• Consultation — a focused session to assess a sourcing, scheduling, or design challenge
Available with US business-hours overlap. Invite me to your job or send a message — you will receive a direct, honest assessment of scope, cost, and timeline within hours.
Sakib Ahamed
Steps for completing your project
After purchasing the project, send requirements so Sakib can start the project.
Delivery time starts when Sakib receives requirements from you.
Sakib works on your project following the steps below.
Revisions may occur after the delivery date.
Review your inputs and confirm scope
I check your files, confirm units, material, and critical dimensions, and flag anything unclear before modeling starts.
Model and draft in SolidWorks
Parametric part/assembly modeling, then manufacturing drawings with GD&T. You get a mid-project check-in for anything ambiguous.
