You will get welding fixture and jig's design for biw and heavy machinery
Project details
I am a CSWP Certified Mechanical Design Engineer with 4+ years of experience in welding fixture design, industrial tooling, and production-ready mechanical systems. I specialize in designing robust, accurate, and manufacturable welding fixtures used in automotive BIW lines and heavy machinery fabrication.
My focus is always on precision, repeatability, and production efficiency.
What I Offer
BIW welding fixture design
Geo fixtures and re-spot fixtures
Manual and robotic welding fixtures
Heavy machinery welding jigs
Tack welding fixtures
Modular fixture concepts
Pneumatic clamp integration
Locator, pin, and rest pad
3D modeling and assembly
2D manufacturing drawings with tolerances
BOM preparation
Design Considerations Covered
3-2-1 locating principle
Clamp accessibility and ergonomics
Weld gun accessibility
Datum structure and tolerance stack-up
My focus is always on precision, repeatability, and production efficiency.
What I Offer
BIW welding fixture design
Geo fixtures and re-spot fixtures
Manual and robotic welding fixtures
Heavy machinery welding jigs
Tack welding fixtures
Modular fixture concepts
Pneumatic clamp integration
Locator, pin, and rest pad
3D modeling and assembly
2D manufacturing drawings with tolerances
BOM preparation
Design Considerations Covered
3-2-1 locating principle
Clamp accessibility and ergonomics
Weld gun accessibility
Datum structure and tolerance stack-up
Materials
MetalField of Expertise
Appliances, Automotive, MachineryDesign Software
AutoCAD, Creo, SolidWorksFile Format
DWG, PDF, SLDASM, SLDDRW, STEPWhat's included
| Service Tiers |
Starter
$40
|
Standard
$60
|
Advanced
$90
|
|---|---|---|---|
| Delivery Time | 2 days | 3 days | 5 days |
Number of Revisions | 3 | 3 | 3 |
Number of 3D Renders | 1 | 1 | 1 |
Number of Technical Drawings | 6 | 20 | 30 |
Concept Development | |||
3D Model | |||
Source Files | - |
Optional add-ons
You can add these on the next page.
Fast Delivery
+$10 - $20
Additional Technical Drawing
(+ 1 Day)
+$20
Source File
(+ 1 Day)
+$20Frequently asked questions
About Shubham
3D Product Design, Fabrication, Tools & Fixtures
Indore, India - 7:11 am local time
My core expertise includes: • SolidWorks 2026 (Advanced) – Parametric modeling, assemblies, and detailed drawings
• Industrial Equipment like Tools and fixtures(Welding, Machining, Inspections), Material Handling Equipment and Jig's.
• Sheet Metal Design – Enclosures, fabrication drawings, flat patterns (DXF)
• Product Design & Development – From concept to manufacturable solution
• 3D Printing (FDM, SLA, SLS) – DFAM, STL optimization, prototyping
• CNC & Fabrication Drawings – Laser cutting, machining-ready files
• Reverse Engineering – STL/scan to parametric CAD models
I have hands-on experience designing: • Welding fixtures, hydraulic fixtures, and industrial equipment
• Sheet metal enclosures and structural assemblies
• Plastic components and 3D printable products
• CNC-ready furniture and complex assemblies
I understand real-world manufacturing processes including cutting, bending, machining, and assembly, ensuring every design is not just theoretical but ready for production.
I am available for both short-term tasks and long-term collaborations.
Steps for completing your project
After purchasing the project, send requirements so Shubham can start the project.
Delivery time starts when Shubham receives requirements from you.
Shubham works on your project following the steps below.
Revisions may occur after the delivery date.
Requirement Discussion
Understand component geometry, welding process, production volume, and client requirements Review CAD files, drawings, tolerance requirements, and welding sequence
Concept Development
Create initial fixture concept with locator and clamping strategy Decide fixture structure, operator accessibility, and welding clearances Share concept for approval before detailed design
